Freewing has modeled this brilliant aircraft in EPO foam with a 70mm electric ducted fan (EDF) power system. With a 1306mm length and 878mm wingspan, this 1/12 scale flying replica including many exciting features! An accurate scale outline with sharp surface details and panel lines make this model stand out at your airfield.
- Spannweite: 878mm
- Länge: 1306mm
- Fluggewicht: 2000g
- Material: EPO Schaum
- Regler bis 6S Lipo
- 12 Blatt EDF Impeller
- Elektrisches Fahrwerk vorhanden
DATA SHEET
| Type of kit: | PNP |
| Wingspan (mm): | 34.57in / 878mm |
| Length (mm): | 51.4in / 1306mm |
| Flying weight (gr) | 2000g (approx) |
| CG (Center of Gravity) | 90mm / 3.5" from the leading edge of the wing at the root |
| Servos | 4x 9 gr metal gear, 1x 9 gr metal gear inversed |
| Direction of Rotation (EDF Rotor) | Classic Counter Clock Wize (CCW) |
| EDF Diameter Class (mm): | 70 |
| Blades: | 12 |
| Power System | 3048-2100Kv Brushless Outrunner |
| Motor Type: | Out-Runner |
| Electronic Speed Control | 60 A |
| Battery Cells: | 6s - 22.2v |
| Battery Capacity (mAh) | 4.000 mAh |
| Connection: | EC-5 |
| Surfaces | Ailerons, Rudder, Elevator |
| Landing Gear | Retractable |
| Material | EPO Foam, Carbon reinforcements |
| Build time | 2 heures |
| Radio requise | 4 channels minimum |
| Recommended pilot skill level | Intermediate, Advanced |
Technical specifications
- Durable EPO Foam and Reinforced Construction
- Realistic Shape and Detailing
- Electric Retractable Landing Gear
- 12 Blade EDF Fan For Realistic Sound
- Removable Wings and Magnetic Nose Cone for Easy Transport
- Minimal Assembly
- Three Decal Sets Included
- Optional Weapon Set (Sold Separately)
- Optional Suspension Strut Set (Sold Separately)
Includes
- Freewing 6S-Upgrade F-16 70mm EDF Jet - PNP
- PNP version - 2h are required to complete the building
Requires
- 4+ Channel 2.4 GHz Full Range Radio
- 4+ Channel 2.4 GHz Full Range Receiver
- 6 Cell 22.2V 3600 - 4000 mAh Li-Po Battery with EC5 Connector
- 4-6 Cell Li-Po Battery Charger
Spezifikationen
| Länge [mm] | 1306 |
| Gewicht [g] | 1800 |
| Zellen max. [LiPo] | 6 |
| Zellen min. [LiPo] | 6 |
| Modelltyp | Vorbildähnlich |
| Spannweite [mm] | 878 |
| Nurflügel | 0 |
| Bausatzausführung | PNP |
| Schwierigkeitsgrad Bau | 3 |
| Schwierigkeitsgrad Flug | 6 |
| Antrieb | Elektro |
| Fluggewicht [g] | 2000 |
| Material Rumpf | Formschaum |
| Material Fläche | Formschaum |
